Class-D power amplification retains digital signal path right to the speaker outputs
DSD128 5.6MHz
Native Tidal and Qobuz support
LUMIN App volume control
NEW analogue input via adapter
Effortlessly plays everything from DSD128 5.6MHz through high-res PCM to mainstream formats FLAC, Apple Lossless, MP3 and Internet radio streams.
Play your local music collection, stream from TIDAL, Qobuz and AirPlay and now connect external sources too using the included adapter!
SPECIFICATIONS:
-
DSD SUPPORT:
- DSD128 5.6MHz, 1-bit
-
OUTPUT:
- PHYSICAL: Stereo 4 mm banana binding posts
-
SPEAKER LOAD: >= 4 Ohm
-
RATED POWER OUTPUT (PER CHANNEL):
60W @ 8 Ohm Speaker
100W @ 4 Ohm Speaker
-
INPUT:
- Analogue RCA stereo and mini-jack input via included USB adapter
- Existing owners can purchase the adapter seperately -
-
POWER SUPPLY:
- 100–240V AC auto-ranging
-
PHYSICAL:
- 361mm (W), 323mm (D), 58mm (H), 4.5kg
-
STREAMING PROTOCOL:
- UPnP AV protocol with audio streaming extension
- Gapless Playback
- On-Device Playlist
-
SUPPORTED AUDIO FILE FORMATS:
-
DSD LOSSLESS:
- DSF (DSD), DIFF (DSD), DoP (DSD)
-
PCM LOSSLESS:
- FLAC, Apple Lossless (ALAC), WAV, AIFF
-
COMPRESSED (LOSSY) AUDIO:
- MP3, AAC (in M4A container)
-
-
SUPPORTED AUDIO SAMPLE RATES, BIT DEPTHS, NUMBER OF CHANNELS:
- PCM, 44.1kHz - 384kHz, 16 - 32bit, Stereo
- DSD, 2.8MHz - 5.6MHz, 1bit, Stereo
-
SUPPORTED CONTROL DEVICES:
- All models of Apple iPad (v2 or later). iOS 5.0 or later required. Full Retina Display support.
-
APP FEATURES:
- High-resolution artwork. Artwork caching. AirPlay compatibility. Multiple-tag handling. ‘Composer’ tag support. Find & Filter. Tag browsing. Native Tidal and Qobuz support.
-
INPUT:
- Ethernet Network 1000Base-T
- USB storage, flash drive, USB hard disk (Single-partition FAT32, NTFS and EXT2/3 only)
-
FINISH:
- Raw brushed aluminium
-
OTHER:
- Firmware-upgradable for further features and enhancements
