Alchemy PPA-2 Phono Preamplifier
Alchemy PPA-2 Phono Preamplifier
Alchemy PPA-2 Phono Preamplifier
Alchemy PPA-2 Phono Preamplifier
Elac

Alchemy PPA-2 Phono Preamplifier

Regular price $1,999.99 $0.00 Unit price per

Shipping : FREE in Canada

Alchemy PPA-2 Phono Preamplifier

Introducing the ELAC Audio Alchemy PPA-2 Phono Preamplifier, a testament to the art of preserving and enhancing the timeless warmth of vinyl records. Merging cutting-edge technology with a profound respect for analog audio, this preamplifier redefines the vinyl listening experience. With meticulous attention to detail and a commitment to sonic purity, the PPA-2 transports you into the heart of your vinyl collection, unveiling the richness and authenticity of each track.

Exceptional sound quality

The PPA-2 is designed to extract the maximum amount of detail from your vinyl records. Its fully discrete, balanced FET topology, DC servo-controlled output stage, and precise continuously variable MC cartridge loading settings all contribute to its outstanding sound quality.

Toroidal Transformer

This design's inherent characteristics, such as reduced electromagnetic interference and noise, ensure a clean and stable power delivery to the preamplifier's circuitry. By minimizing magnetic field leakage and providing a more efficient and regulated voltage output, the toroidal power supply significantly reduces unwanted noise and interference, preserving the authenticity and fidelity of the analog audio signal extracted from vinyl records.

Versatility

The PPA-2 is compatible with a wide range of MM and MC cartridges. It also has a variety of user-adjustable settings, such as continuously variable input impedance and high-pass filter, that allow you to fine-tune the sound for your specific system.


FEATURES

• Fully discrete, balanced FET topology
from input to output
• DC servo-controlled output stage
• Switchable MM or MC gain for each channel
• MC loading continuously adjustable from 5 Ω to
999 Ω
• Precise MC cartridge loading settings for each
input can be displayed on the LCD information
screen
• Selectable Stereo or Mono operation
• Highly precise RIAA equalization using 0.1% metal
film resistors and selected metalized polypropylene
capacitors
• Selectable rumble filter
• All signal routing through hermetically sealed gold-ongold relays
• Ultra-low-noise DC voltage regulators
• Microcontroller completely shuts down during normal
operation to eliminate any clocking noises
• Internally shielded toroidal transformer and linear
power supply for very low radiated hum field
• Provides an improved power source for the Miracord 70
and 90 turntable motor
• Liquid Crystal Display for clear user information



SPECIFICATIONS

Inputs  (2) RCA UNBALANCED or (1) RCA & (1) XLR BALANCED
Input impedance  5-1KOhms variable or 47K
Frequency Response 10hz-20khz +/- 0.2dB
RIAA accuracy  +/- 0.2dB
Nominal THD+N <0.005%
Signal-to-noise ratio (1kHz) >86dB
Output Voltage  >6.0V RMS
Crosstalk (L-to-R or R-to-L) >80dB
Single ended Gain  42dB (low) or 60dB (high)
Balanced Gain  48dB (low) or 66dB (high)
Output Impedance  50 ohms
Analog Outputs  (1) XLR BALANCED, (1) RCA UNBALANCED
Available finishes  Black
Dimensions (HxWxD)  2" x 17.5" x 15" including jacks
Weight  12 lbs
