Aspen FR10 Loudspeaker (Pair)
Aspen FR10 Loudspeaker (Pair)
Aspen FR10 Loudspeaker (Pair)
Aspen FR10 Loudspeaker (Pair)
PS Audio

Aspen FR10 Loudspeaker (Pair)

Regular price $13,999.00 $0.00 Unit price per

Shipping : FREE in Canada

shipping : free in canada, roc en apply

Introducing the FR10, a revolution in compact speaker design. Perfectly tailored for smaller spaces and enhanced accessibility, this speaker stands at just 41 inches tall, 8 inches wide, and 75 pounds, making it a sleek and powerful addition to any room.

With its innovative 8-inch planar midrange, the FR10 delivers the same high-quality sound and cutting-edge technology found in larger models like the FR30, all condensed into a more manageable size. By relocating the planar midrange below the tweeter, we've ensured optimal listening height while maintaining the speaker's overall compactness.

The FR10 also boasts impressive bass response, thanks to two new 6.5-inch woofers that reach down to 30Hz. These are complemented by three passive radiators discreetly tucked away on the back of the speaker, maximizing surface area for exceptional performance.

To further enhance performance, we've redesigned the cabinet construction, incorporating through bolts for increased structural rigidity. This not only improves the speaker's overall durability but also allows for easy access to the internals, ensuring hassle-free maintenance.

Experience the future of compact speaker design with the FR10, where innovation meets accessibility without compromising on sound quality.

Specifications

  • FULL-RANGE 3-WAY SYSTEM
  • 86.5 dB SENSITIVITY
  • ONE 2.5" PLANAR RIBBON TWEETER
  • 8" PLANAR RIBBON MIDRANGE
  • TWO 6.5" LOW DISTORTION HIGH EXCURSION WOOFERS
  • THREE 6X9” HIGH EXCURSION PASSIVE RADIATORS
  • NON-WOVEN CARBON FIBER SKIN ON ROACELL FOAM CORE WOOFER CONES
  • THERMOSET FIBERGLASS RESIN FRONT BAFFLES
  • SMOOTH AND FULL OFF AXIS RESPONSE
  • ONE PIECE CABINET FOR EASY SETUP
  • SOFT RUBBER FEET WITH REMOVABLE STAINLESS STEEL SPIKES AND MILLED ALUMINUM TOP CAP NUT
  • EASY TO POSITION FOR BEST PERFORMANCE
  • HEAVY INTERNAL BRACING FOR LOW CABINET VIBRATION
  • CUSTOM FILM CAPACITORS & PREMIUM AIR-CORE INDUCTORS
  • MAGNETICALLY ATTACHED GRILLES
  • MILLED, GRAINED AND ANODIZED ALUMINUM BASE
Weight & Dimensions

Color Options: Satin White, Satin Black
Enclosure Type: Passive radiator (three 6x9” oval rear-firing)
High Frequency Transducer: 2.5” planar magnetic with Teonex diaphragm
Mid Frequency Transducer: 8” planar magnetic with Teonex diaphragm
Low Frequency Transducer: 2 x 6.5” woofers, cast frame, non-woven carbon fiber PMI foam sandwich cone, advanced magnet structure
Crossover Frequency: 550 Hz, 1750 Hz - Linkwitz-Riley 4th order acoustic
Sensitivity (2.83V @ 1M): 86.5 dB
Nominal Impedance: 4 ohm (3.3 ohm minimum impedance)
Recommended Amplifier Power: 50-200W
Frequency Response: 32 Hz-20 kHz (-6dB) half space, 25 Hz (-6 dB) in-room
Dimensions (HxWxD): 41.5” x 11.75” x 16.25” with base (8” width not including base)
Net Weight: 75 lbs (34.1 kg)
