AudioControl Concert XR-6 A/V Surround Amplifier
AudioControl Concert XR-6 A/V Surround Amplifier
AudioControl Concert XR-6 A/V Surround Amplifier

AudioControl Concert XR-6 A/V Surround Amplifier

Regular price $7,399.99 $0.00 Unit price per

9.1.6 IMMERSIVE AV receiver

AudioControl’s next generation of high-performance AV receivers enable home theater specialists and integrators to create systems that deliver new levels of precision, power and control. The Concert XR-6 supports the most sought after immersive surround formats, such as Dolby Atmos, Auro-3D, DTS:X, and IMAX Enhanced, with 16-channels of unbalanced outputs including four user-configurable outputs. The Concert XR-6 offers a full complement of inputs for connection to the latest audio/video components, including 7 HDMI 2.0b inputs that fully support 4K UHD and HDR playback.

The new Concert XR-6 houses the very latest in audio and video processing technology, featuring Dirac Live® room correction to overcome acoustic anomalies in any space, and ESS SABRE PRO DACs that ensure unprecedented levels of detail and clarity along with earth-shaking, authoritative bass response. Seven amplified channels deliver 100 watts per channel.

Enthusiasts will enjoy intuitive app-based control, Google Cast, AirPlay 2, Roon Ready, aptX Bluetooth and Wi-Fi streaming connectivity options as well as integrated web-based configuration.

All of this outstanding technology has been wrapped quite elegantly within a completely new industrial design, distinguishing AudioControl’s home cinema preamp/processor lineup from any other solution.


  • 9.1.6 decoding for Dolby Atmos and DTS:X
  • IMAX Enhanced, Auro-3D
  • 4K UHD supporting HDMI 2.0b and HDCP 2.2
  • ES9026PRO SABRE audiophile DACs (124 dB of dynamic range)
  • Dirac Live® room correction
  • Class AB power amplification
  • 16 channel unbalanced outputs
  • Dolby VisionTM playback support
  • HDR support (HDR10/BT.2020)
  • 4 user-assignable output channels
  • 7 HDMI inputs / 3 HDMI outputs (eARC compatible)
  • IP, IR, RS232, and Wifi control
  • Google Cast and AirPlay2 streaming support
  • Roon Ready


    • Audio Inputs: 7 HDMI, 6 RCA Phono, 4 Coax SPDIF, 2 Toslink
    • Nominal sensitivity: 1V, 2V, 4V (user selectable)
    • Input Impedance: 47 kΩ
    • Signal to Noise (A-wtd ref 100W) normal/stereo direct: 100 dB/110 dB
    • Frequency Response: 20 Hz – 20 kHz ± 0.2 dB
    • Video Inputs: 7 HDMI (HDMI 2.0b / HDCP 2.2)


    • Amplifier Channels: 7
    • Continuous power output, per channel, 8Ω / 4Ω:  100W/100W
    • Minimum Speaker Load: 4Ω
    • Preamp Audio Outputs: 16 channels (balanced XLR), 16 channels (unbalanced RCA), 2 channels zone 2 (unbalanced RCA), 1 Toslink
    • Nominal output level: 1 Vrms (max. 5 Vrms)
    • Output impedance: 560 Ω
    • THD+N (20 Hz – 20 kHz): -100dB
    • Main Video Outputs: Dual (2) HDMI (eARC support)
    • Second Zone Output: 1 HDMI
    • Headphone Output: 1 1/4″


    • IP Ethernet
    • Wifi
    • RS232 Serial Control
    • 12 Volt Trigger Outputs: 2
    • IR Receiver Inputs: 2

    • Power consumption (standby): <0.5W
    • Power consumption (idle, typical): 90W (340 BTU/hour)
    • Power consumption (maximum): 1500W (5200 BTU/hour


    • Dimensions (including terminals and feet): 17”W x 17.5”D x 7.3”H (4U)
    • Weight: 40.3 lbs. (18.3 kg)

    IN THE BOX: Concert XR-6, HTR-3 remote with 2 x AAA batteries, DAB/FM antenna, 3 x WiFi/Bluetooth antennas, calibration microphone, USB cable, power cord, user manual, warranty
