Product Details
BHK Signature Preamplifier
Preamplifiers are at the heart of any high-performance music system. They are the critical controlling interface between our sources of music and our loudspeaker chain. Most preamplifiers do a fine job of control and isolation, but only a rare handful make magic happen. Add the BHK Signature Preamplifier into your system and suddenly you are enveloped in a wealth of musicality you’ve not yet experienced: deeper, wider, sound staging, improved separation of instruments and voices, subterranean bass, extended highs, and an openness you're unlikely to have experienced without this instrument in the system.
Technology
Overview
The BHK Signature Preamplifier is one of the most remarkable musical instruments in the world. It is the perfect interface between your sources and power amplifier. Designed by Bascom H. King, the BHK Signature distills Bascom’s 50 plus years of high-end audio design experience into a single masterpiece of audio amplification. “This is the best sounding preamplifier I have ever designed or heard,” and that’s saying a lot for a man of Bascom’s experience. Preamplifiers play a critical role in any separates audio system, strategically positioned between sources of music: CD players, phono preamps, DACs, tape recorders and tuners – and your power amplifier – the preamp serves essential roles of control and isolation. Control is simple in concept, but extraordinarily difficult to design in an acoustically transparent manner. Control duties such as input switching, volume, balance, and amplification can place unwanted acoustic thumbprints on the music if not designed with extraordinary care. The challenge in any design is to do as little damage to music’s purity as possible. What our Master Designer, BHK, has built will not only stand the test of time, but represents one of the finest musical instruments ever built to honor the music.
Inside Story
At the heart of any preamplifier are the gain stage that provides the amplification, and the volume control that manages how loud or soft the music plays. Inside the BHK Signature Preamp a pair of hand-selected and matched 12AU7 dual triode vacuum tubes provides the unit’s gain. Volume is controlled by a GainCell controling the actual gain of the vacuum tube. This offers the cleanest, lowest impact gain control in precise, half-dB steps. A massive, high-current transformer feeds the BHK Signature Preamp's power supply, which ensures that the unit can reproduce music with a wide dynamic range, without compression or distortion. Painstaking through-hole construction is used, along with the finest, hand-selected components: PRP resistors, high grade Audiophile capacitors---even the solder was auditioned for the best sound. Nothing was spared in the execution of Bascom King's design. Fully-balanced circuitry with a bandwidth that extends almost to DC on the low end and well above audibility on the high end are responsible for the effortless presentation of music BHK preamplifier owners enjoy. First time listeners remark at how much better-defined the space around instruments and vocals appears; the improvements in sound quality are nothing short of ground breaking. Openness, transparency, increased space around instruments---voices come alive in ways most never thought possible.
The Build
Bascom King has said, “vacuum tubes are simply more convincing and musically accurate than any other input configuration I have ever tried,” and the BHK Signature preamplifier proves his statement. All inputs, whether single-ended or balanced, are converted to a pure balanced signal by the dual triode vacuum tube for lowest distortion, highest linearity performance. Input switching is accomplished through hand-selected double-pole double-throw, gold plated relays that we’ve chosen for their sonic neutrality. The signals, once selected, are passed directly to the revolutionary new multi-stage attenuator controlling both volume and balance. High-performance analog audio products like the BHK Preamp benefit from the use of through-hole discrete parts in the signal path. Hand-selected through-hole PRP resistors, high grade Audiophile capacitors and the finest discrete parts are used throughout the BHK Signature preamplifier. Nothing was spared in its design. Even the solder we use has been auditioned for best sound. Extended signal bandwidth---from below 0.1 Hz to above 100 kHz--- is partly responsible for the effortless presentation of music produced by the BHK preamplifier. A massive power supply with an oversized toroidal transformer, the Class A MOSFET output circuit ensure that the BHK Preamplifier will effortlessly drive any cable or amplifier.
Specifications - BHK Signature Preamplifier
Physical
|
|
| Unit Weight |
22 lbs [9.97 kg] |
| Unit Dimensions |
17” x 14” x 4” [ 36cm x 43cm x 10cm] |
| Shipping Weight |
31 lbs [14 kg] |
| Shipping Dimensions |
20.5”x 24” x 10” [52cm x 61cm x 25cm] |
Power requirements
|
|
| Input Power |
Model specific 100VAC, 120VAC, or 230VAC 50 or 60Hz |
| Power Consumption |
60W |
Audio inputs
|
|
Coaxial RCA single ended
XLR Balanced |
5
5 |
Input Impedance
Unbalanced (RCA)
Balanced (XLR) |
33KΩ minimum
66KΩ minimum |
| Sensitivity |
Unbalanced 1.3V/33KΩ
Balanced 1.3V/66KΩ |
Audio Outputs
|
|
Coaxial RCA single ended
XLR Balanced |
2
2 |
Analog Audio Output
|
|
| Output level |
4.0 Vrms |
| Output Impedance |
<100Ω |
Frequency Response
20-20KHz |
+/- 0.1dB |
| THD&IM @ 1KHz (full scale) |
<0.03% |
| Bandwidth |
-3dB 0.1Hz - 200kHz |
DC Triggers
|
|
| +12V |
2 |
Headphone Performance
|
|
Output Power
300Ω
16Ω > |
>200mW
4.0 Watts |
| S/N Ratio |
>90dB (1KHz) |
| THD & IM 1 volt out |
<0.02% |
| Output Impedance |
<0.5Ω |
