THE PERFECT ADD ON

The special external power supply PSU-10 has been designed to enhance the performance of the phono stage Gold Note PH-10, thanks to its Super Inductive Dual Choke hybrid design.
It features an inductive filter on the analogue stage and a dual choke design powered by a double inductor driving both the negative and positive high-current stages. The Gold Note proprietary Dual Choke design perfectly filters the signal voltage to eliminate any interference and electrical noise from the AC power system.
With its massive power supply, it provides a shield from the AC power grid. By achieving complete insulation, an ideal working environment is created for the phono stage PH-10 to perform at its best.

 ULTRA-CLEAN POWER

The large and ultra-clean power generated enhances noise reduction, greater dynamic, better resolution, and finer audio details guaranteeing the best realism and musicality.
Dedicated to the PH-10 phono stage, the PSU-10 features 4 power supply stages with 4 ultra-low-noise voltage regulators. The device is powered by 4 transformers ( 3 dedicated to the power supply and 1 for the inductive dual choke special filter).

IMPORTANT! – FOR PH-10 WITH SERIAL NUMBER LOWER THAN 56802

The PH-10 must be updated to the latest firmware in order to be powered by the PSU-10, to learn how you can update your PH-10 please visit the Download area on this website.



IMPROVES THE PERFORMANCE OF YOUR PH-10



The PSU-10 is the perfect match for our award-winning phono stage PH-10. Add the dedicated external power supply to take the PH-10 to the next level and enjoy your records with improved details and realism.



Technical

  • Four rail audio grade power supply
  • Four ultra-low noise voltage regulator
  • +12V, +5V for logic
  • +/- 14V for analog with inductive noise remover
  • Line regulation for all output 0,05 %/V
  • Load regulation for all output 0,05 %Vu
  • Line noise rejection >80dB
  • Common mode noise rejection >80dB
  • Full power response time <2,5uSecPower
  • Main supply 100/120 & 220/240V automatic selection; 50 or 60 Hz
  • Nominal power: 25W
  • Dynamic power: >50W
  • Stand by power: <1W
  • 20mm L x 80mm H x 260mm D
  • 5 kg
