ECM 1 MKII DAC/Streamer
ECM 1 MKII DAC/Streamer
Electrocompaniet

ECM 1 MKII DAC/Streamer

Regular price $8,000.00 $0.00 Unit price per

Shipping : FREE in Canada

The new ECM 1 MKII is a DAC and music streamer. With the brand new, in-house developed streaming software and app, it plays lossless, DSD and high-resolution digital content in a way that really makes you want to dig deeper into all the delightful music out there.

The streamer is very powerful, flexible and easy to use. It plays directly from Tidal, Spotify and Qobuz and can be fed through AirPlay, DLNA or Bluetooth.

Specifications:

Technical Data
  All measurements are made at 120V / 240V  //50Hz / 60Hz

No. of channels 2
Output Impedance 300 Ohms
Noise floor (20 - 20 kHz) < -145 dB
Frequency response 0.5 - 48 kHz
THD+N < 0,0005 %
Upsampling rate 192 kHz, 24 bit
Digital/Analog conversion 192 kHz, 24 bit

Input sampling rate:
2 x SPDIF Coax  192 kHz, 24 bit
2 x SPDIF TOSLink  192 kHz, 24 bit

Network connection: Wi-Fi or LAN

Internal drive:

Docking, self installation. 3.5"/2.5" - unlimited capacity.


Supported audio formats: All popular formats including: WAV/WAVE, MP3, AAC+, Vorbis, ALAC, FLAC, APE, AIFF, WMA, up to 192kHZ/24bit, DSD, up to DSD 128 (5.6 MHz)

Supported control interfaces: DLNA, UPnP, Android and iOS remote
Internal storage: docking, self installation


Streaming services:

• AirPlay ®
• AirPlay 2 ® *
• Spotify ® Connect
• Qobuz ®
• TIDAL ®
• TIDAL ® Connect *
• Roon Ready
• DLNA
• Internet Radio
• Bluetooth streaming from any Bluetooth enabled device

Future software update.


Power consumption
(no load or signal)
50 W
 standby  0.5 W

Dimensions

Width 470 mm / 18.5 inches
Depth 381 mm / 14.99 inches
Height 80 mm / 3.14 inches
Weight

8.3 kg. / 18 lbs.

*(without internal drive)
