PH-1000 Phono Stage

Shipping : FREE in Canada

THE MOST ADVANCED PHONO STAGE

A unique piece of audio engineering designed to be innovative in every possible way and 100% made in Italy. Featuring Class-A exclusive discrete components, a Class-A headphone output, +40 EQ curves preset, 4 custom EQ curves manually adjustable, and the high-quality Class-A line preamp which comes as an optional. For the first time ever, you will be able to play virtually any record the way it’s meant to be thanks to more than 40 EQ curves available, or even customise the EQ curves manually by adjusting three main parameters – that’s why the PH-1000 is a complete game-changer, opening a new era in vinyl reproduction.

PERFECT CARTRIDGE MATCHING

With 14 Gain and 14 Load levels, as well as 6 Capacitance options dedicated to MM cartridges, it is the ideal phono stage for high-performance analogue systems, capable of driving even the most exotic of cartridges with perfect synergy, making the PH-1000 a professional instrument for high- end studio recording.

On top of that, you can change settings and make ultra-fine adjustments, including the EQ curve, on the go by simply using the SKC and the display as you are playing music. Our innovative technology allows the best ease of use while preserving entirely the sound quality as it works in the analogue domain: the interface is digital and independent from the audio path, which is completely analogue. The result is an ultra- low noise phono stage with high gain and no audio filters. All the functionalities are in fact managed through discrete audio-grade components and sealed single switches, always shortening the signal path to deliver superior audio quality and extract even the finest details from the vinyl record. Powered by our custom firmware, the PH-1000 can be easily updated via computer when necessary.

MAXIMUM FLEXIBILITY

The PH-1000 offers 3 independent inputs, two RCA and one XLR. There are also 2 other inputs, one RCA and one XLR, that can be used either for the external load plugs for even finer control of the Load or as line inputs on the PH-1000 with Preamp. Add the other functionalities, such as the Headphone Output, the Stereo/Mono control with phase inversion, the L/R Channel Swap and the Rumble Subsonic Filter and here you have it, the most advanced phono stage on the market. The level of quality meets the highest standard throughout the entire production: from the aluminium ultra-solid chassis machined with precision to the electronic components and circuitry that undergo strict QC computer-controlled tests. 40+ EQ CURVES: RIAA, Capitol, Columbia/CBS, Deutsche Grammophon, Decca London USA, Decca London UK and Decca Mono 78rpm, Epic, HMW, Mercury, RCA Victor, Philips, Elektra, L’Oliseau-Lyre, Parlophone, and more. Each curve can be “enhanced” with our proprietary technology inspired by the Neumann Cutting Lathe for superior dynamic and musicality. The PH-1000 shows every detail on the colour display powered by our proprietary firmware. With the SKC [Single Knob Control technology] and the display, you have an intuitive system to easily control the phono stage and quickly make fine adjustments without even interrupting the playback.

You can now enjoy the shortest audio path ever with the PH-1000, your turntable and your headphones – that’s all you need for the audio signal to go from the vinyl directly into your headphones without the need of additional stages. Front Panel and Case: Brushed anodized aluminum available in three colors: Black | Silver | Gold

Main Details

Frequency response: 20Hz – 20KHz. EQ Curves: +20 EQ presets 4 custom setups (infinite variable curves) all with “Enhanced” option @ +/- 0.3dB max. THD (Total Harmonic Distortion) <0.01% max. Signal to Noise Ratio: -100db. Dynamic Range: 110db. Infrasonic Filter: 10Hz/36db octave (ON/OFF). Mono/Stereo: Stereo, Stereo 180°, Mono, Mono 180°, Mono L. Channel Swapping: R/L, L/R. IR Receiver: For multifunction remote control. Dimensions: 430mm W | 135mm H | 375mm D, Weight: 12 Kg
Inputs and OutputsAudio Inputs: 2x RCA (0.1mV MC up to 8.0mV MM), 1x XLR (0.1mV MC). Load: 12 options for RCA [100KΩ, 75KΩ, 47KΩ, 33KΩ, 22KΩ, 1KΩ, 470Ω, 220Ω, 100Ω, 47Ω, 22Ω,10Ω + external load], 8 options for XLR [4K7Ω, 1KΩ, 470Ω, 220Ω, 100Ω, 47Ω, 22Ω,10Ω + external load]. Capacitance MM: 100pF, 150pF, 220pF, 330pF, 470pF, 1000pF. Gain: 65dB MC, 40dB MM with 7 options [-9dB, -6dB, -3dB, 0dB, +3dB, +6dB, +9dB]. Line Inputs Level: 2Vrms (standard) up to 2,5Vrms (max). Audio Inputs: 1x RCA (@1Volt), 1x XLR (@4Volt), 1x Output Stereo for Tube (Balanced GN) for optional Tube-1006 & Tube-1012. Output Impedance: 50Ω. Output Level: 2Vrms (standard) up to 2.5Vrms (max)
Power consumption: 30W. PSU Input for optional special external power supply PSU-1000 or PSU-1250. Power Supply: Dual-Mono linear power supply 100-240V with automatic selection. Fuse: 2-amp, Fast Blow, 5mm x 20mm
