Gold Note

PST-10

Regular price $1,650.00 $0.00 Unit price per

Shipping : FREE in Canada



Beauty and Innovation Merged in One Creation

The PST-10 is a super inductive power supply designed for all Gold Note low voltage powered Turntables. PST-10 has been engineered with the best quality audio-grade components to enhance the performance of Gold Note Turntables and improve your audio system getting the very best music experience out of your LP’s. PST-10 features a dual choke design powered by a double inductor driving the negative and positive high current stages and featuring an inductive filter on the analogue stage. The power supply performs 4 transformers, 3 of which are strictly dedicated to the power supply while 1 transformer exclusively powers the inductive filter and the two chokes. The Gold Note proprietary Dual Chokes Design perfectly filters the signal voltages in order to eliminate all the possible electrical pollution coming from the AC power system. The PST-10 uses its massive power supply to shield the turntables from electromagnetic interferences thus insulating it effectively from the AC power system. The large, ultra-clean power enhances super low noise, greater dynamic, better resolution and finer details for a more realistic high-end audio performance and pure audio pleasure.



Technical:

  • Four audio grade Transformers
  • Four ultra low noise voltage regulator
  • +12V, +5V for logic
  • 18V/26V/34V output with inductive noise remover
  • Line regulation for all output 0,05 %/V
  • Load regulation for all output 0,05 %Vu
  • Line noise rejection >80dB
  • Common mode noise rejection >80dB
  • Full power response time <2,5usec
  • Power: Mains supply: 100/120V & 220/240V with automatic selection, 50/60Hz
  • Nominal power: 25W
  • Dynamic power: >50W
  • Stand by power: <1W
  • Dimensions: 220mm L | 80mm H | 260mm D
  • Weight: 3 Kg
