TUBE-1012 & TUBE-1006
Shipping : FREE in Canada
Please Contact Us To Order. Thank you.
“A TOUCH OF WARMTH” FOR YOUR ELECTRONICS
ADD SOME WARMTH
TUBE-1012/1006 is the best way to improve the Gold Note electronics even further to reach a whole new level of performance through the class A 12-valve output stage (TUBE-1012) or 6-valve output stage (TUBE-1006). Our sources and amplifications are capable of great control and definition, providing outstanding realism in recreating the musical event. But if you prefer the warm sound of the tubes and want to bring your system to its very top performance, the TUBE-1012 or TUBE-1012 are the way to go. Connect it to your Gold Note electronics and you’ll hear Solid-State and Tubes playing in perfect synergy to deliver the best High-End listening experience.
EASY TO CONNECT, EASY TO USE
Our proprietary Totem-Pole Output Stage design, with six independent audio stages per single tube, guarantees ultra-wide bandwidth response and ultra-low distortion to deliver the purest audio signal ever.
Thanks to new audio inputs on the rear panel our valve output stages can be connected with up to two sources at the same time using the TUBE INPUT for the Gold Note sources and the LINE INPUT for other manufacturers. The input can be easily selected from the front panel for maximum convenience and ease of use.
TECHNICAL SPECIFICATIONS
TUBE-1012/1006
Totem-Pole Output Stage design
MAX INPUT (THD < 1%)
12Vrms on XLR
6Vrms on RCA
MAX OUTPUT (THD < 1%)
16V on XLR
8Vrms on RCA
OUTPUT IMPEDANCE
<600Ω
GAIN
2dB
RECOMMENDED LOAD
>10kΩ
TUBES
TUBE-1012 – 12 valves
TUBE-1006 – 6 valves
THD+N
0.0028% @ 1kHz – 1.736V
S/N
>100dB @ 1kHz – 1.736V
POWER CONSUMPTION
TUBE-1012 – 80W
TUBE-1006 – 50W
POWER SUPPLY
100-120V or 220-240V, 50/60Hz
Super Linear Vacuum Tube Regulator with 4 Inductive Choke filters
