Gold Note Tuscany (Gold and Red) MC Cartridge
Gold Note Tuscany (Gold and Red) MC Cartridge
Gold Note

Gold Note Tuscany (Gold and Red) MC Cartridge

Regular price $7,800.00 $0.00 Unit price per

Shipping : FREE in Canada

SPECIAL ORDER

Beauty and Innovation Merged in One Creation

The exclusive design of the Tuscany Gold features an extra thin Micro Ridge diamond tip developed with Adamant-Namiki, the world most famous professional Diamond manufacturer. The Micro Ridge diamond tip special multi-faced shape cut guarantees the best deep vinyl groove contact available today. The diamond tip is mechanically inserted and blocked into the new telescopic Boron cantilever hold by a Titanium pipe increases the rigidity of the structure. The Titanium pipe is finely machined from a single block of metal in 4 spokes that handle the cartridge silver micro coils hilt by a Teflon spacer enabling great rigidity while allowing a perfect alignment building precision to get the best tracking ability. The non-deformable harmonic steel cantilever suspension is blocked with gold plated nut on the bottom side of the crossbar gold case positioned behind the micro-coils Teflon spacer rigidly blocked to the structure avoiding unwanted vibration affect the perfect solid groove tracking ability of the cartridge. The Tuscany Gold cube designed body offers a gorgeous structural rigidity while allowing a very intuitive and precise VTA adjustment easy to see the flat bottom line. The 7050 alloy increased the lighted body of the cartridge is
strategically injected with fluid polymers to provide a pronounced dampening control effect. The redesigned thinner and longer gold plated pin connectors enable a wider better contact with arm cinch, a better contact stops energy dispersion while enabling better grounding for a more silent music background to reach all minor details of the music the best. The Tuscany Gold extra light precision hand-wrapped pure silver
micro-coils enable 4ohm internal impedance and 0.25mV output level may be driven by quality active MC phono preamplifier without the need of Step-Up transformers. The Italian high-quality finishes and exotic design of the Tuscany Gold last for a lifetime pleasure of music listening for the real highest demand. Please Note: to preserve the uniqueness all Tuscany Gold & Red cartridges have the serial number indelibly printed in the engraved area of the top of the cartridge body. The body cubic design of the Tuscany Red offers a prodigious structural rigidity while allowing a precise VTA adjustment for the easy to see the flat bottom line. Besides the increased lighted body of the cartridge made of 7050 injected alloy enables superb vibration control. The Tuscany Red helped by its 20ohm high internal impedance and the 0.35mV output level can be easily matched with any MC active phono preamp without Step-Up transformers. Italian high-quality finishes and design of the Tuscany Red last for a lifetime pleasure of music listening.



Red

  • Typology: MC Low Output
  • Output Level: 0.35mV
  • Frequency response: 10-50000Hz
  • Impedance: 20 ohm
  • Suggested load: >200 ohm
  • Compliance: 10×10-6cm/dyne
  • Channel separation: >30dB
  • Suggested tracking weight: 1.8 to 2.1g
  • Cantilever: Boron
  • Diamond: Micro Ridge
  • Diamond Size: 2.5×75μm
  • Coil Wire: Copper
  • Magnet: Samarium-Cobalt
  • Mounting hole diamond distance:
  • 6.5mm
  • Weight: 11 grams
  • Body: 7050 Duraluminium alloy

Gold

  • Typology: MC Low Output
  • Output Level: 0.25mV
  • Frequency response: 5-55000Hz
  • Impedance: 4 ohm
  • Suggested load: >50 ohm
  • Compliance: 10×10-6cm/dyne
  • Channel separation: >35dB
  • Suggested tracking weight: 1.8 to 2.1g
  • Cantilever: Boron
  • Diamond: Super Micro Ridge
  • Diamond Size: 2.5×75μm
  • Coil Wire: Silver
  • Magnet: Samarium-Cobalt
  • Mounting hole diamond distance:
  • 6.5mm
  • Weight: 11 grams
  • Body: 7050 Duraluminium alloy
