JL Audio
JL Audio Fathom SAv2 Home Amplifier
JL Audio Fathom SAv2 Home Amplifier
Couldn't load pickup availability
ULTIMATE POWER AND CONTROL
This amplifier is purpose-engineered to deliver jaw-dropping output capabilities in almost any home theater or home audio system.
1000- AND 2000-WATT POWER OPTIONS
DESIGNED TO DRIVE SINGLE OR DUAL FATHOM CTS SUBWOOFERS
FIXED OR VARIABLE LEVEL CONTROL OPTIONS
CHOICE OF BALANCED (XLR) OR UNABALNCED (RCA) INPUTS
BUILT-IN, OPTIMIZED EQ CURVES
READY FOR TABLETOP OR RACK MOUNTING
ADVANCED CLASS-D AMPLIFIER DESIGN
Innovative, high-speed switching design synchronizes an amplifier’s power supply and output channels, resulting in top-flight fidelity with ultralow noise and distortion.
PRECISION TUNING
Perfectly tune your system to the room with variable phase control and a low-pass filter that can be adjusted from 30 Hz to 130 Hz.
COMPLETE CUSTOMIZATION
Our extreme low frequency (e.l.f.) trim lets you adjust the bass response from -12 decibels to +3 decibels at 25 Hz, so you can have perfect control of the low end of your system.
DIGITAL AUTOMATIC ROOM OPTIMIZATION (D.A.R.O.) TECHNOLOGY
Exclusive D.A.R.O. technology from JL Audio uses a powerful onboard DSP to automatically optimize the subwoofer’s in-room frequency response. This leads to a superb listening experience, no matter where the subwoofer is placed.
HIGH-DAMPING FEEDBACK CIRCUITRY
This proprietary, discrete control circuit design allows our Class-D switching amplifiers to maintain excellent damping factors for improved transient behavior and fidelity.
General |
|
| Light modes | off, on or dim |
|---|---|
| Amplifier Power (RMS) | 1000 W or 2000 W RMS short-term (depending on model) |
| Power modes | off, on or automatic (signal-sensing) |
| Warranty | 3 years |
Signal Processing |
|
| Unbalanced input(s) | Stereo or mono (two RCA jacks) |
|---|---|
| Balanced input(s) | Stereo or mono (two female XLR jacks) |
| Input grounding | Isolated or grounded |
| Input modes | Master or slave |
| Level control | Reference (fixed gain) or Variable, from full mute to +15 dB over reference gain |
| Filter mode(s) | Low-pass |
| Filter slope(s) | 12/24 dB/octave |
| Filter frequency range | 30 Hz-130.1 Hz |
| Filter defeat function | |
| Polarity | 0 or 180º |
| Phase | Variable, 0-270º, referenced to 80 Hz |
| Output to slave | Balanced (one male XLR jack) |
| Calibration mode | Digital Automatic Room Optimization (D.A.R.O.), includes laboratory-grade microphone |
Amplifier Specifications |
|
| Width (W) | 17.4" (442 mm) |
|---|---|
| Height (H) | 3.5" (89 mm) |
| Depth (D) | 17.9" (455 mm) |
| Net weight (each) | 13.5": 35 lbs (15.9 kg) Dual 13.5": 43 lbs (19.5 kg) |
