MCINTOSH MHT200 HOME THEATER RECEIVER(Pre-owned)
MCINTOSH MHT200 HOME THEATER RECEIVER(Pre-owned)
MCINTOSH MHT200 HOME THEATER RECEIVER(Pre-owned)
MCINTOSH MHT200 HOME THEATER RECEIVER(Pre-owned)
Altitudo Audio

MCINTOSH MHT200 HOME THEATER RECEIVER(Pre-owned)

Regular price $3,000.00 $0.00 Unit price per



(Pre-owned)

*Original box

This McIntosh A/V System Controller was fully serviced in our lab where it received a new power supply, which is a common failure in this model (after 20 years).  It now works just like it left the factory and produces all the sweet sounding power expected from a McIntosh amplifier.

This is a full featured receiver including an AM/FM tuner, which was an optional add-on (TM1) Module to this receiver when it was originally released.  And yes the component video switching is a bit outdated, but most people just run HDMI directly from their cable box / streaming box to the display anyway in order to get the purest connection possible.

This unit would also make an excellent home theater preamp as the jumpers connecting the amplifier section are removable. A nice upgrade path if you decide you want even more power down the line.

Standout Features:
•  Separate Listen and Record Input Selection - The 7 Analog A/V and 6 Digital Audio Inputs can be reassigned for any desired signal sources. All six digital inputs can be assigned to any A/V signal source. Separate Record and Listen Circuits allow recording of one program source while listening to another.
•  LED Indicators - The MHT200 includes thirty-three LEDs on the Front Panel. These LEDs indicate the Operating/Decoding Modes, Power Guard Activation, Surround Modes, Zone Selection, Late Night Dynamic Processing and the Trim Adjustments.
•  Patented Power Guard - All channels include the patented McIntosh Power Guard circuit that prevents the amplifier from being over driven into clipping, with its harsh distorted sound that can also damage your valuable Loudspeakers.

Click here for a PDF copy of the original Owner's Manual

Preamplifier and Processor Specifications:
Frequency Response
Left, Center, Right, Left Surround, Right Surround, Left Back, Right Back:
±0.5dB from 20Hz-20,000Hz

Subwoofer1
±0.5dB from 20Hz-140Hz

Total Harmonic Distortion
0.05% for all channels

Signal To Noise Ratio
Greater than 90dB A weighted

Tone Controls
±12dB from the flat setting

Power Amplifier Specifications:
Rated Power Band (80Hz to 20,000Hz) into a 4 ohm load
2 x 160 watts
3 x 140 watts
5 x 130 watts
6 x 120 watts

Rated Power Band (80Hz to 20,000Hz) into a 8 ohm load
2 x 100 watts
3 x 95 watts
5 x 85 watts
6 x 80 watts

Dimensions
Front Panel: 17-3/4 inches (45.09cm) wide, 9-7/16 inches (23.97cm) high. Depth behind front mounting panel is 19 inches (48.26cm) including clearance for connectors. Panel clearance required in front of mounting panel is 1-1/8 inches (2.9cm).

Weight
73 pounds (33.1Kg)
