*Pre-owned
The NEO iDSD
The NEO iDSD is our new 3-in-one DAC/amp. With balanced ‘PureWave’ circuitry, unbeatable hi-res Bluetooth5.0 and MQA, it is the ultimate in hi-res playback.
Place it horizontally or vertically to suit its surroundings. The OLED display flips to match orientation. One rotary knob controls functionality.
Enjoy the NEO iDSD as a pure DAC. Connect it to a separate integrated amp or preamp using the fixed-level analogue output.
Or treat it as a DAC/preamp with a variable output. The ideal companion to a power amp or active speakers.
And headphone users will love using the excellent amp stage to create a fabulous ‘head-fi’ system.
Specifications:
- Digital :
- USB3.0 B (USB2.0 compatible)/S-PDIF (coaxial/optical)
- Bluetooth 5.0™( AAC, SBC, aptX, aptX HD, aptX Adaptive, aptX LL, LDAC, LHDC/HWA Codec)
- Formats
- DSD512/256/128/64, Octa/Quad/Double/Single-Speed DSD
- DXD (768/705.6/384/352.8kHz), Double/Single-Speed DXD
- PCM (768/705.6/384/352.8/192/176.4/96/88.2/48/44.1kHz)
- MQA
- Bluetooth 96kHz
OUTPUTS:
- Balanced XLR : 6.3V / 7.7V max. (variable) 4.4V fixed
- UnBAL RCA : 3.2V / 3.9V max. (variable) 2.2V fixed
ZOUT:
- Balanced : <= 100Ω
- UnBAL : <= 50Ω
- SNR : -112dB(A) @ 0dBFS (UnBAL/BAL)
- DNR : >116dB(A) @ -60dBFS (UnBAL/BAL)
- THD + N : <0.0015% @ 0dBFS (UnBAL/BAL)
Headphone Section:
- Output Balanced :
- >6.4V/68.6 mW (@ 600Ω)
- >5.77V/1040 mW (@ 32Ω)
- UnBAL :
- >3.25V/17.6 mW (@ 600Ω)
- >3V/295 mW (@ 32Ω)
- Output Impedance : <1Ω (UnBAL/BAL)
- SNR : -112dBA (3.3V UnBAL/6.2V BAL)
- THD + N : <0.0015% (125mW @ 32Ω)
- Power consumption : : No Signal ~0.5W
- Max Signal : ~2.5W
- Dynamic range : -120dB(A)
- Input voltage : DC 5V/2.5A, AC 100 -240V, 50/60Hz (with iPower)
- Dimensions :
- 214 x146 x 41 mm
- 8.4" x 5.7" x 1.6"
- Weight : 970 g (2.14 Ibs)
