The Elector is a fully analog stereo preamplifier from SPL, offering pure analog signal path for those who prefer analog sources or use a separate DAC. It’s intended for serious hi-fi setups: clean, high-voltage analog output, flexible input routing, and classic preamp control features like volume, input selection, and tape monitor. It’s designed to enhance and preserve signal integrity, offering wide dynamics, low noise and excellent compatibility with amplifiers, headphones or active speakers.
Key Features
• All-analog signal path — no internal DAC or digital processing
• High-voltage analog stage for wide dynamic range and low distortion
• 6 stereo analog inputs (balanced XLR + unbalanced RCA) — flexible source support
• Balanced (XLR) and unbalanced (RCA) stereo outputs — compatibility with many downstream amplifiers or devices
• Tape monitor / insert loop for external processing or playback devices
• Remote-controllable volume (motorized potentiometer) with front-panel VU meters for monitoring signal level
• Solid build quality and classic preamplifier ergonomics — ideal for analog & hi-fi purists
Specifications
| PRODUCT | SPL Elector Analog Preamplifier |
| Analog Inputs (Stereo) | 3 × Balanced XLR (10 kΩ) ; 3 × Unbalanced RCA (47 kΩ) |
| Maximum Input Level | +32.5 dBu |
| Analog Outputs | 1 × Balanced XLR ; 1 × Unbalanced RCA (Direct Out) |
| Output Impedance | 75 Ω (balanced) |
| Maximum Output Level | +32.5 dBu |
| Frequency Response | 10 Hz – 200 kHz |
| Crosstalk (1 kHz) | –108 dB |
| Total Harmonic Distortion (THD) | ~0.0099% |
| Noise (A-weighted) | –102.5 dB |
| Dynamic Range | 135 dB |
| Internal Supply Voltages | ±60 V (analog rails) |
| Power Supply | 115 / 230 V AC (switchable), max 40 VA |
| Dimensions (W × H × D) | 278 × 100 × 337 mm |
| Weight | 4.25 kg (unit only) |
