Stellar M700 Monoblock Amplifiers

Regular price $4,599.00 $0.00 Unit price per

Shipping : FREE in Canada

shipping : free in canada, roc en apply

Product Details

The Stellar M700 mono amplifiers are a massively powerful engine capable of effortlessly driving demanding loudspeaker loads to concert levels.

Enjoy an unheard of level of control and command from your loudspeakers with the Stellar M700, one of the most extraordinary under $5,000 power amplifier pair ever crafted. With its mighty 700 watt engine connected to any sized loudspeaker, the M700 monoblocks deliver extraordinarily effortless linear headroom that seems to go on forever. Dynamics like you’ve rarely experienced before. Slam, control, toe-tapping pacing, and music’s subterranean depths are effortlessly delivered to any loudspeaker from the most efficient to the most demanding. Revel in rich layers of fine, full detail you might have been missing before Stellar. Marvel at the deep, extraordinary, wall-to-wall soundstage. Control your loudspeakers as never before. Effortless. Lush. Stellar.


DESIGN

The hybrid approach used in the Stellar M700 Power Amplifier takes advantage of the best traits technology has to offer. Its all important input stage relies upon the Analog Cell to provide a zero-loss interface between the preamplifier and DAC, as well as imprint the amp's sonic character. The perfected analog voltage is then converted into the high current output needed to effortlessly drive your loudspeakers.

APPLICATION

The M700 is Stellar's best. Rated at 350 watts into 8Ω and 700 watts into 4Ω, a pair of these placed on any loudspeaker brings forth the lush, rich, and soul-satisfying power of two completely independent power blocks with headroom to spare. The listening experience with the M700 starts feet tapping and smiles breaking out. One listen to a hugely loud and complex musical passage effortlessly rendered by the M700 pair and you'll know you made the right choice.


Specifications

Stellar M700 Mono Amplifier

Unit Weight 13 lbs [5.9 kg] (each)
Unit Dimensions 17”W x 3”H x 12”D (13″D w/connectors)
17”W x 6”H x 12”D (Stacked)
Shipping Weight 16.5 lbs [7.5 kg] (each)
Shipping Dimensions 22”W x 8”H x 17”D (each)
Color Options Black
Silver
Voltage Options
(Factory set only)
Japan 100V
North America 120V
Europe/Asia/Australia/New Zealand 230V
Mains Power Inputs IEC C14
Idle Power Consumption 23W
Accessories Included US (NEMA 5-15P) (all versions)
Schuko (CEE7/7) (230V version)
UK (BS 1363) (230V version)
Audio Inputs RCA (Unbalanced)
XLR (Balanced)
Speaker Outputs Copper base nickel plated binding posts (2 pair)
DC Trigger Input 3.5mm 5-15VDC
Warranty 3 years parts and labor

Signal

Gain 30.5dB +/-0.5dB
Sensitivity for rated output power 1.6V
Noise 1kHz@700 Watts < -105dB
Input impedance Unbalanced 50KΩ
Balanced 100KΩ
Output Impedance 50Hz, 2.8VRMS <0.007Ω
Damping factor 50Hz. 2.8VRMS
8Ω >1100
4Ω >550
Frequency Response 2.8VRMS into 4Ω
10Hz – 20KHz +/- 0.5dB
10Hz – 50KHz +0.1/-3.0dB

THD&IM

1KHz, 1W/4Ω <0.02%
10-20KHz, 1W/4Ω <0.02%
10-50KHz, 1W/4Ω < 0.05% (90kHz BW)
1KHz, 87.5W/4Ω < 0.015%

Output Power

120vac mains, 1kHz, 1% THD
8Ω 350W minimum
4Ω 700W minimum
2Ω Stable for musical transients
