TEAC
TEAC VRDS701T CD Transport
TEAC VRDS701T CD Transport
Couldn't load pickup availability
The VRDS-701 CD player employs a newly-developed VRDS mechanism and a TEAC original discrete DAC.
The VRDS is a TEAC-original CD drive mechanism that reduces rotation vibration and other unwanted vibration by clamping the CD to an aluminum turntable with the same diameter in order to maximize inertial mass.
Used in combination with a UD-701N, which is part of the same series, playback is possible
using the discrete DAC in the UD-701N as well as with MQA full decoding.
Of course, you can also use it together with a DAC of your choosing, and build a system as you like.
The inclusion of a 10MHz clock input enables flexible integration
with systems that are synchronized using an external clock.
Spec description
| CD section | |
| Supported media | Audio CD, CD (CD-R/CD-RW) * 8cm CDs not supported. |
| Digital audio outputs | |
| COAXIAL | |
| Connector | RCA × 1 |
| Output level | 0.5Vp-p |
| Output impedance | 75Ω |
| OPTICAL | |
| Connector | TOS (JEITA RC5720C) × 1 |
| Clock sync input | |
| Connector | BNC × 1 |
| Input frequency | 10MHz |
| Input impedance | 50Ω |
| Input level | |
| Rectangle wave | Equivalent to TTL level |
| Sine wave | 0.5 to 1.0Vrms |
| External control | |
| Trigger in (12V TRIGGER IN) | |
| Connector | 3.5mm Mono mini jack × 1 |
| Input level | 12V, 1mA |
| Trigger out (12V TRIGGER THRU) | |
| Connector | 3.5mm Mono mini jack × 1 |
| Output level | 12V |
| Maximum curret supply | 100mA |
| Power | AC120V, 60Hz AC220-240V, 50/60Hz |
| Power consumption | 10W |
| Standby power | 0.4W |
| Overall dimensions | 444 (W) × 111 (H) × 333 (D) mm (including protrusions) |
| Weight | 10.1kg |
| Operating temperature | +5℃ to +35℃ |
| Operating humidity | 5％ to 85％ (no condensation) |
| Storage Temperature range | −20℃ to +55℃ |
| Included accessories | AC cord, Remote control (RC-1338), Foot pads × 3, Owner's manual |
* RoHS complied.
* Design and specification may subject to change without notice.
